CCNA 200-301 Portable Command Guide, 6th Edition

The CCNA 200-301 Portable Command Guide summarizes all Cisco CCNA 201-301 certification-level Cisco IOS Software commands, keywords, command arguments, and associated prompts, providing you with tips and examples of how to apply the commands to real-world scenarios. Throughout, configuration examples give you a better understanding of how these commands are used in simple network designsand its portable enough to use whether youre in the server room or the equipment closet.

This edition has been fully updated to reflect the latest Cisco CCNA 200-301 certification objectives and new technologies shaping todays enterprise networks, including automation, programmability, and security-driven design. Whether youre preparing for the exam or working in the field, youll find this guide an indispensable resource for verifying commands, recalling configuration steps, and applying Cisco best practices.

New and Updated Coverage Includes

• Network Fundamentals: IPv4/IPv6 addressing, subnetting, VLSM, summarization, cabling, interfaces, and CLI essentials
• LAN Switching Technologies: VLANs, trunking, inter-VLAN routing, STP, EtherChannel, CDP, LLDP, and verification commands
• Routing Technologies: Static and dynamic routing, single-area OSPFv2 and OSPFv3 configuration, route summarization, and neighbor adjacency
• IP Services: DHCP, NAT, NTP, SNMP, Syslog, and device management fundamentals
• Security Fundamentals: Secure device access, port security, ACLs, DHCP snooping, dynamic ARP inspection, and device hardening
• Wireless Technologies: WLAN configuration, security settings, and basic troubleshooting for access points

Key Features:

• Quick, portable reference for all CCNA-level Cisco IOS commands
• Logical topic organization for fast lookup and practical learning
• Real-world configuration examples and verification output
• Compact and durableideal for data centers, classrooms, or fieldwork
• Create Your Own Journal section for personalized notes and lab results
• Ideal for last-minute review before the CCNA exam
