End-to-End QoS Network Design: Quality of Service for Rich-Media & Cloud Networks, Rough Cuts, 2nd Edition

Rough Cuts

  • Available to Safari Subscribers
  • About Rough Cuts
  • Rough Cuts are manuscripts that are developed but not yet published, available through Safari. Rough Cuts provide you access to the very latest information on a given topic and offer you the opportunity to interact with the author to influence the final publication.

Not for Sale
  • Description
  • Sample Content
  • Updates
  • Copyright 2014
  • Dimensions: 7-3/8" x 9-1/8"
  • Pages: 900
  • Edition: 2nd
  • Rough Cuts
  • ISBN-10: 0-13-311609-3
  • ISBN-13: 978-0-13-311609-0

This is the Rough Cut version of the printed book.

End-to-End QoS Network Design

Quality of Service for Rich-Media & Cloud Networks Second Edition

New best practices, technical strategies, and proven designs for maximizing QoS in complex networks

This authoritative guide to deploying, managing, and optimizing QoS with Cisco technologies has been thoroughly revamped to reflect the newest applications, best practices, hardware, software, and tools for modern networks.

This new edition focuses on complex traffic mixes with increased usage of mobile devices, wireless network access, advanced communications, and video. It reflects the growing heterogeneity of video traffic, including passive streaming video, interactive video, and immersive videoconferences. It also addresses shifting bandwidth constraints and congestion points; improved hardware, software, and tools; and emerging QoS applications in network security.

The authors first introduce QoS technologies in high-to-mid-level technical detail, including protocols, tools, and relevant standards. They examine new QoS demands and requirements, identify reasons to reevaluate current QoS designs, and present new strategic design recommendations. Next, drawing on extensive experience, they offer deep technical detail on campus wired and wireless QoS design; next-generation wiring closets; QoS design for data centers, Internet edge, WAN edge, and branches; QoS for IPsec VPNs, and more.

Tim Szigeti, CCIE No. 9794 is a Senior Technical Leader in the Cisco System Design Unit. He has specialized in QoS for the past 15 years and authored Cisco TelePresence Fundamentals.

Robert Barton, CCIE No. 6660 (R&S and Security), CCDE No. 2013::6 is a Senior Systems Engineer in the Cisco Canada Public Sector Operation. A registered Professional Engineer (P. Eng), he has 15 years of IT experience and is primarily focused on wireless and security architectures.

Christina Hattingh spent 13 years as Senior Member of Technical Staff in Unified Communications (UC) in Cisco’s Services Routing Technology Group (SRTG). There, she spoke at Cisco conferences, trained sales staff and partners, authored books, and advised customers.

Kenneth Briley, Jr., CCIE No. 9754, is a Technical Lead in the Cisco Network Operating Systems Technology Group. With more than a decade of QoS design/implementation experience, he is currently focused on converging wired and wireless QoS.

n Master a proven, step-by-step best-practice approach to successful QoS deployment

n Implement Cisco-validated designs related to new and emerging applications

n Apply best practices for classification, marking, policing, shaping, markdown, and congestion management/avoidance

n Leverage the new Cisco Application Visibility and Control feature-set to perform deep-packet inspection to recognize more than 1000 different applications

n Use Medianet architecture elements specific to QoS configuration, monitoring, and control

n Optimize QoS in rich-media campus networks using the Cisco Catalyst 3750, Catalyst 4500, and Catalyst 6500

n Design wireless networks to support voice and video using a Cisco centralized or converged access WLAN

n Achieve zero pac

Table of Contents

<>Introduction xxxvi

Part I: QoS Design Overview

Chapter 1 Introduction and Brief History of QoS and QoE 1

History and Evolution 2

    Then 3

    Now 3

    Evolution of QoS 4

QoS Basics and Concepts 5

    User Expectations: QoS, QoE, and QoX 5

    QoS Models: IntServ and DiffServ 6

    Fundamental QoS Concepts and Toolset 7

    Packet Headers 8

    Simplifying QoS 9

Standardization and Consistency 9

Summary 11

Further Reading 11

    General 11

    IntServ 12

    DiffServ 12

Chapter 2 IOS-Based QoS Architectural Framework and Syntax Structure 13

QoS Deployment Principles 13

QoS Architectural Framework 14

    QoS Behavioral Model 15

    QoS Feature Sequencing 15

Modular QoS Command-Line Framework 16

    MQC Syntax 17

    Default Behaviors 19

    Traffic Classification (Class Maps) 19

    Definition of Policies (Policy Maps) 20

    Attaching Policies to Traffic Flows (Service Policy) 22

    Hierarchical QoS and HQF 23

    Legacy QoS CLI No Longer Used 25

AutoQoS 26

Summary 29

Further Reading 29

    General 29

    AutoQoS 29

Chapter 3 Classification and Marking 31

Classification and Marking Topics 31

    Classification and Marking Terminology 32

    Security and QoS 33

        Trust Boundaries 33

        Network Attacks 34

    Classification Challenges of Video and Wireless Traffic 34

    Marking Fields in Different Technologies 35

        Field Values and Interpretation 35

        Ethernet 802.1Q/p 37

        Ethernet 802.11 WiFi 38

        ATM and FR 38

        IPv4 and IPv6 39

        L2 and L3 Tunnels 39
