CCNA Data Center DCICN 640-911 Official Cert Guide, Premium Edition eBook and Practice Test
The exciting new CCNA Data Center DCICN 640-911 Official Cert Guide, Premium Edition eBook and Practice Test is a digital-only certification preparation product combining an eBook with enhanced Pearson IT Certification Practice Test. The Premium Edition eBook and Practice Test contains the following items:

* The CCNA Data Center DCICN 640-911 Premium Edition Practice Test, including more than 400 practice exam questions and enhanced practice test features
* PDF and EPUB formats of the CCNA Data Center DCICN 640-911 Official Cert Guide from Cisco Press, which are accessible via your PC, tablet, and smartphone

About the Premium Edition Practice Test

This Premium Edition contains an enhanced version of the Pearson IT Certification Practice Test (PCPT) software with more than 400 practice test questions. In addition, it contains all the chapter-opening assessment questions from the book. This integrated learning package

* Enables you to focus on individual topic areas or take complete, timed exams
* Includes direct links from each question to detailed tutorials to help you understand the concepts behind the questions
* Provides unique sets of exam-realistic practice questions
* Tracks your performance and provides feedback on a module-by-module basis, laying out a complete assessment of your knowledge to help you focus your study where it is needed most

Pearson IT Certification Practice Test minimum system requirements:
Windows XP (SP3), Windows Vista (SP2), Windows 7, or Windows 8.1 (desktop UI only); Microsoft .NET Framework 4.0 Client; Pentium class 1GHz processor (or equivalent); 512 MB RAM; 650 MB disc space plus 50 MB for each downloaded practice exam; access to the Internet to register and download exam databases

About the Premium Edition eBook

CCNA Data Center DCICN 640-911 Official Cert Guide from Cisco Press enables you to succeed on the exam the first time and is the only self-study resource approved by Cisco. Expert instructors and engineers Wendell Odom and Chad Hintz share preparation hints and test-taking tips, helping you identify areas of weakness and improve both your conceptual knowledge and hands-on skills.

This complete, official study package includes

* A test-preparation routine proven to help you pass the exam
* "Do I Know This Already?" quizzes, which enable you to decide how much time you need to spend on each section
* Chapter-ending and part-ending exercises, which help you drill on key concepts you must know thoroughly
* The powerful Pearson IT Certification Practice Test software, complete with hundreds of well-reviewed, exam-realistic questions, customization options, and detailed performance reports
* A final preparation chapter that guides you through tools and resources to help you craft your review and test-taking strategies
* A Nexus lab guide appendix, with advice for building hands-on Nexus labs
* Study plan suggestions and templates to help you organize and optimize your study time

Well regarded for its level of detail, study plans, assessment features, and challenging review questions and exercises, this official study guide helps you master the concepts and techniques that ensure your exam success.

The official study guide helps you master topics on the CCNA Data Center DCICN 640-911 exam, including

* Networking fundamentals
* Installing, operating, and configuring Nexus switches
* VLANs and trunking concepts and configuration
* Spanning Tree Protocol (STP) concepts and configuration
* IP addressing and subnetting
* IPv6 fundamentals
* Cisco Nexus IPv4 routing configuration and routing protocol implementation
* IPv4 access control lists (ACL) on Nexus switches
